30 The Bond

This internationally recognised building has set the standard in environmental performance, workplace design and cost-efficiency.


Location

  • Sydney, Australia

Sector

Service

  • Environmentally Sustainable Design
  • Building Services
  • Building Wellness
  • (View all)

Client

  • Deutsche Bank

Project Status

  • Completed 2004

Awards

  • 2004 Architectural Bulletin - NSW for Building of the Decade 2000’s
  • 2004 Australian Property Institute - NSW for Property Development, Environmental Development and Heritage Award
  • 2004 Engineering Excellence Awards - Australia for Environment and Heritage Award
  • 2004 Engineering Excellence Awards - NSW division for Energy Efficiency and Heritage Award
  • 2004 Master Builders Association Awards - NSW for Innovation, Commercial Building - $25m to $80m Award, Energy
  • 2004 National Association of Women in Construction for Innovation, Construction and Design Award
  • 2004 NSW Urban Taskforce - Development Excellence Award
  • 2005 Australian Construction Achievement Award - Winner
  • 2005 Energy Australia National Trust Heritage Awards for Best Adaptive Reuse of a Heritage Building by Government or Corporation, and Conservation - Energy Management Award
  • 2005 National and NSW Property Council of Australia Rider Hunt Awards
  • 2005 RAIA Architecture Awards for Commercial Buildings and Energy Efficiency/ESD
  • 2005 RAIA National Award Commendation for Interior Architecture
  • Efficiency Award and Restoration/Renovation of an Historic Building - $5m - $10m Award

Architect

  • Lend Lease Design, Whittaker Hadenham Openshaw and PTW Architects

Located at the edge of Sydney Harbour, close the heart of the city’s historic Rocks precinct, this redevelopment included integrating heritage aspects of the former gasworks site into a new commercial building with innovative urban design and environmental objectives.



30 The Bond also sought to offer enhanced flexibility to its tenants and a new standard of Grade A office space. From the building’s conception, the client committed to creating a new benchmark in sustainability for commercial building design.



Balancing Performance with Heritage

We were involved from the start of the project to ensure the building met its sustainability vision. To achieve its environmental benchmarks, we used passive chilled beams, which at the time, was an Australian first. This system delivers fresh air and maintains ideal temperatures sustainably and with significant cost-savings.



To control solar gain and mitigate glare, the building’s main west facing façade is active. External blinds operating on a timer and by individual adjustment maximise comfort for occupants and allow them to have full-water views of Sydney Harbour.



The 5-storey heritage-listed exposed sandstone rock wall on the east boundary has become synonymous with the building. It was made by placing a linear grille at the wall’s base. This scavenged potentially difficult moist air and used that air to ventilate the underground car park.



The project required full design and documentation of leading-edge mechanical services, including:

  • Mixed mode winter garden air conditioning
  • A dual temperature chilled water thermal plant
  • Primary air de-humidification systems
  • Increased net lettable area
  • Reduced building height



Key Achievements

This multi-award-winning building was Australia’s first commercial office building to achieve a 5 Star ABGR base building rating (now known as NABERS) and exceeds the 5 Star targets by 20 per cent. It is also the first building in Australia to achieve a certified 5 Star Green Star – Office As-Built rating.



The building has recorded superior indoor air quality, substantial energy reduction and greenhouse gas emission at about 48 per cent lower than the average for conventional Sydney offices.  To date, 30 The Bond has won more than 35 awards.

Area
20000 sqm
Height
9 storeys
